20ft High Cube One-Trip Shipping Container — Portable Systems Housing — New
Built with an extra foot of height for generators, data systems, battery packs, and portable equipment enclosures. This 20ft high cube container system housing delivers 15% more interior volume than a standard 20ft container — providing the clearance, floor space, and structural integrity required for portable system installations that a standard container cannot accommodate.
Furthermore, every unit arrives brand new in as-new condition — built new, shipped once, and never previously loaded. As a result, the interior is clean, residue-free, and ready for immediate system installation, fit-out, or modification without preparation work on arrival.
Moreover, the all Cor-Ten steel construction and ISO standard corner castings make this container fully compatible with crane lift, forklift transport, and flatbed or stepdeck trailer delivery to any site in Australia.
20ft High Cube Container Dimensions
| Measurement | Metric | Imperial |
|---|---|---|
| External Length | 6,058 mm | 20′ |
| External Width | 2,438 mm | 8′ |
| External Height | 2,896 mm | 9’6″ |
| Internal Length | 5,898 mm | 19’4″ |
| Internal Width | 2,352 mm | 7’8″ |
| Internal Height | 2,698 mm | 8’10” |
| Door Opening Width | 2,340 mm | 7’8″ |
| Door Opening Height | 2,585 mm | 8’5″ |
| Floor Area | 14.86 m² | 160 sq ft |
| Internal Volume | ~39 m³ | ~1,380 cu ft |
Weight Specifications
| Measurement | Weight |
|---|---|
| Tare Weight (Empty) | 2,300 kg |
| Payload Capacity | 27,700 kg |
| Maximum Gross Weight | 30,000 kg (30 ton) |
20ft High Cube Container Systems Housing Specifications
Condition: One-Trip (New) — Never previously loaded.
| Feature | Detail |
|---|---|
| Construction | All Cor-Ten steel — rust and corrosion resistant |
| Flooring | 28mm hardwood timber on steel cross-members |
| Doors | Exterior hinged double doors — full-width end opening |
| Door Seals | Rubber gaskets — weatherproof and watertight |
| Locking Bars | 2 per door — heavy-duty steel |
| Lockbox | Factory-fitted — padlock protection on door handles |
| Forklift Pockets | 2 per side — 4 total |
| Ventilation | 4 vents — passive airflow |
| Corner Castings | ISO standard forged steel — crane and twistlock compatible |
| CSC Plate | Yes — max gross weight 30 ton |
| ISO Standard | ISO 668 Series 1 |
High Cube vs Standard 20ft — Volume Comparison
| Specification | Standard 20ft | High Cube 20ft |
|---|---|---|
| Interior Height | 2,385 mm | 2,698 mm |
| Internal Volume | ~33.2 m³ | ~39 m³ |
| Volume Advantage | — | ~15% more interior cube |
| Generator / System Clearance | Often insufficient | Sufficient for most portable systems |
The additional 313mm of interior height and 15% volume advantage make this the correct container for portable system installations. Therefore, it accommodates tall generators, battery racks, server stacks, and packaging systems that cannot fit within a standard 20ft container profile.
20ft High Cube Container Systems Housing Key Features
- One-Trip condition — built new, shipped once, sold in as-new condition
- 15% more interior volume than a standard 20ft container
- 2,698mm interior height — accommodates generators, battery racks, and tall portable systems
- All Cor-Ten steel construction — rust, corrosion, and impact resistant
- ISO standard corner castings — crane lift, forklift, and twistlock compatible
- CSC plated to 30 ton maximum gross weight
- Factory-fitted lockbox — secures high-value system installations
- 2 locking bars per door — forced entry resistant
- 4 forklift pockets (2 per side) — easy site repositioning
- 28mm hardwood timber floor — rated for heavy equipment base loads
- 4 passive vents — heat and vapour management for enclosed system operation
- Deliverable to locations throughout Australia
20ft High Cube Container Systems Housing Applications
Generator and Power System Housing
The High Cube interior accommodates diesel generators, transfer switches, and fuel system components that exceed standard container clearance. Furthermore, the 4 passive vents provide baseline airflow for heat management around running generator sets. As a result, this container suits remote site power installations, construction site power distribution, and emergency backup power systems.
Data and Communications Systems
Server racks, UPS systems, communications cabinets, and network equipment install cleanly in the High Cube interior. Moreover, the clean One-Trip interior eliminates contamination risk from prior cargo residue — critical for sensitive electronics installations in containerised data environments.
Battery Storage and Energy Systems
Battery storage systems — including large-format lithium, lead acid, and flow battery configurations — require interior height and floor load capacity that standard containers cannot reliably provide. Therefore, the High Cube profile and 30 ton CSC-plated gross weight make this the preferred base unit for off-grid and grid-tied containerised energy storage.
Packaging and Processing Systems
Portable packaging lines, filling systems, and processing equipment install inside the High Cube container for rapid site deployment. Additionally, the all Cor-Ten steel construction protects equipment from weather and site damage during both transit and stationary operation.
Military and Government Applications
Military, emergency services, and government agencies use High Cube containers as deployable equipment enclosures, command facilities, and mobile workshop units. Furthermore, ISO standard corner castings ensure compatibility with military and government intermodal lifting and transport systems.
Industrial and Commercial Use
Retail, wholesale, and industrial operators use this container for secure equipment storage and portable workshop deployment. As a result, it suits any application where a standard 20ft container falls short on interior clearance for the intended system or equipment.
